Compact Flash GPS Card

Integrated GPS processor, and DRAM
Improved multi-path rejection
1920 time/frequency search channels for signal acquisition
All-in-view 12-channel parallel processing
Cold start under 60 seconds
Maximizes GPS position availability
SingleSat updates in reduced visibility
Superior urban canyon performance
FoliageLock for weak signal tracking
Reduce need for external sensors

Technical Specifications :
Chipset: SiRF Star IIe/LP; SiRF Xtrac
General: Frequency: L1, 1575.42 MHz
C/A: 1.023 MHz chip rate
Channels: 12 Channel all-in-view tracking
Antenna Type: Built-in Ceramic patch antenna (External antenna optional)
Accuracy : Position: 10 meters, 2D RMS
7 meters 2D RMS, WAAS corrected
1-5 meter, DGPS corrected
Velocity: 0.1 meters/second
Time: 1 microsecond synchronized to GPS time
Datum : Default: WGS-84
Other: Selectable for other Datum, please contact your dealer
Acquisition Rate: (Open Sky, Stationary ) Standard Mode Sanp Start: 2 sec., average
Hot Start: 8 sec., average
Warm Start: 38 sec., average
Cold Start: 45 sec., average
Reacquisition: 0.1 sec., average
Acquisition Rate: (Open Sky, Stationary ) Xtrac Mode Hot Start: < 4 sec.
Warm Start: < 35 sec.
Cold Start: < 45 sec.
Reacquisition: 100 msec
Continuous: 1 sec.
Sensitivity Xtrac Mode : Tracking: 16dB-Hz
Hot Start: 23dB-Hz
Warm Start: 28dB-Hz
Cold Start: 32dB-Hz
Dynamics Conditions : Altitude: 18,000 meters (60,000 feet) max.
Velocity: 515 meters/second (1000 knots) max.
Acceleration: 4g, max.
Main Interfaces: Connection: Communication with host platform via CF COM Port
Protocol messages: NMEA 0183 output protocol
Baudrate: 4800 bps
Output format: GGA (1 sec), GSA (1 sec), GSV (5 sec), RMC (1 sec), VTG (1 sec)
Environmental Characteristics : Operating temperature range: -20¡CC to +60¡CC
Humidity range: 5% to 95% No condensing
Power : Operational Power: 3.3 VDC +/- 10%
Input Power: 5 VDC ¡Ó 10%
Operational current: 90 mA (Use external antenna to operate)
Backup Power: 3.3V
Physical Characteristics : PocketXtrack Size: Length 87mm, Width 43mm, Height 34mm
